Elmers Solid Pull Super 7 - 90'

Specifications

Model	Super 7 – 90’	Category Name	Agriculture	Year	2026
Sale Type	New	Manufacturer	Elmers	Tine Size	1/2” Diameter x 22” Long
Total Tines	378	Angle Adjust	90°- 45°	Tine Spacing	1 7/16"
Pull Arm Type	Solid Bar	Harrow Sections	9 x 7 Bar	Vertical Adjust	10"
Main Cart Wheels	550 / 45 - 22.5 (16 ply)	Transport Length	64’ 4”	Recommended Power	450+ Hp
Wing Construction	8”x8”x3/8”	Approximate Weight	15,300 lbs	Harrow Bar Spacing	14” (35.5cm)
Harrow Section Roll	±5°	Wing/Transport Wheels	360 / 60 - 22.5 (16 ply)	Transport Width/Height	15’ Width x 12’10” Height
Hydraulic Outlets Req'd	4	Hitch Frame Construction	4” x 8” - 1/4” Wall Tube	Price	Contact for price CAD

Description

Super 7 – 90’

90’ Solid Pull Arm construction with standard features. MAXLIFE Hardened Harrow Tines – The MAX LIFE process infuses weld-embedded tungsten carbine onto the harrow tine allowing you to harrow in the toughest conditions without worrying about excessive tine wear.

Solid Pull SUPER 7 harrow

The Solid Pull Super 7 Harrow is equipped with solid pull arms and Secure Lock, a custom hydraulic locking system, to increase the harrow's capabilities and safety. It has the same great features as past models, including the 7-bar design and three dimensions of adjustability. The 7-bar design creates up to 40% more harrowing action compared to 5-bar harrows while the three dimensions of adjustability adapt to the needs of your field. The 40-90 degrees of tine angle adjustment allows for more or less harrowing, 10 inches of vertical down pressure for how much pressure is onto the field and section angle control for ideal residue and seedbed management.

FEATURES

ONE HARROW FOR IT ALL

The Solid Pull Super 7 Harrow gives you full control to chop straw, spread residue and incorporate seed and chemicals without compromising on your field finish.

ADAPTABLE TO YOUR NEEDS

Tine Angle, Section Angle and Pitch allow you to set your aggressiveness to your desired field finish whether that is in straw or residue management or in seedbed preparation.

GET 40% MORE DONE PER PASS

The Solid Pull Super 7 Harrow with 7 bars of tines allows you to get 40% more done per pass in comparison to a 5-bar harrow.
